Garrett GBC22-350 44mm Journal Bearing Turbocharger : 200-350 HP #33918

Garrett GBC22-350 44mm Journal Bearing Turbocharger : 200-350 HP #33918

Garrett GBC22-350 44mm Journal Bearing Turbocharger : 200-350 HP

(0 reviews)

Club Line is a product engineered for small engine displacements. This includes powersports, personal watercraft, and automobiles. These turbochargers feature internally wastegated turbine housings and journal bearing rotating groups. GBC stands for GARRETT BOOST | CLUB LINE. The first two numbers indicate the turbo frame size. The larger the number the larger the turbine wheel. The numbers following the dash indicate the peak potential flywheel horsepower rating.

Horsepower: 200 - 350

Displacement: 1.0L - 2.5L

GBC22-350
  • 44mm compressor inducer | 56mm compressor exducer
  • Outline interchangeable with GBC 17 / 20
  • 200 –350 horsepower capability
  • Internal wastegate assembly with calibrated actuator
  • Billet compressor wheel with extended tip design for higher pressure ratio capability
  • GTX Gen II compressor aero with modern gasoline turbine wheel aero
  • Journal bearing rotating group
  • Engineered for small displacement engines including powersports, personal watercraft and automobiles

Compressor Specs:
Wheel Inducer Diameter: 44.0mm
Wheel Exducer Diameter: 56.0mm
A/R: 0.59

Turbine Specs:
Wheel Inducer Diameter: 50.0mm
Wheel Exducer Diameter: 46.0mm
Trim: 84
A/R: 0.64

15%
Details

Ships in 24 hours
SKU GRT-896055-5003S
Retail price: $1163.54
Our price:
$989.01
Want this item shipped out tomorrow, May 29? Order within the next 21 hrs 56 mins.
